How do airplanes fly?

How do airplances fly? From time to time, passengers ask me what it is that keeps an airplane in the air. After all, we’re talking about a metal cylinder weighing some 400,000 kilos. It’s something of a miracle for many people. In fact, though, it’s not rocket science. It has everything to do with aerodynamics and propulsion. So how does an aircraft fly?

Aerodynamics

Aerodynamics is the name for the interplay of forces that drive an object through the air. If we look at a cross section of an aircraft wing, we can see that the upper edge is rounder on the lower edge. Let’s have a look at two air particles. One passes over the wing’s upper edge and the other goes past the lower edge. What we then see is that the air traveling around the upper edge has to travel a greater distance to get around the wing. In other words, the speed of the air around the upper edge is greater than that of the air travelling below the wing.

Some of you may have learned about Bernoulli’s principle in physics at school. It states that, the faster a gas (in this case, air) travels, the lower the pressure it exerts. That’s exactly what’s happening around an aircraft wing. The pressure against the wing’s upper edge is considerably lower than the pressure against the lower edge.

Air Flow

So now we can see the reason why an aircraft flies. We are actually hanging on the air because the pressure against the upper edge of the wing is lower than that against the lower edge. However, the wing does have to be passing through the air. In other words, there must be air flow around the wing in order for the pressure differential to arise.

Then we need engines to create propulsion. They cause the wings to pass through the surrounding air. It creates a balance in which we can see two forces horizontally. First, there is the forward propulsion created by the engines. Opposite that, there is the aircraft’s wind resistance. Vertically, we see the upward lift. And the aircraft weight, pulling it downward.

Flying Without Engines

Even if the engines stopped working—which happens very rarely—aircraft are still capable of gliding great distances. On every flight, as we make our approach for landing, we reduce the engine’s propulsion. Passengers in the cabin can hear this happening. We don’t turn the engine off completely, but they turn because of the air passing through them. So they are not creating any propulsion. In effect, it’s comparable to an engine that has been turned off.

An aircraft’s descent can often take about twenty minutes. During that time—and depending on the aircraft type—we can glide about 120 miles (about 220 kilometres). So, during that time, we’re sitting in a great big glider.

Wing Components

If you happen to be sitting at a window near the wing, you’ll have some interesting things to see. This is where it’s all happening—on the wing’s leading edge, at the rear, and above the wing, you can see all kinds of moving parts.

The wing is designed to provide optimum lift at normal speed, which we call cruising speed. For a jet, that’s about 850 kilometres per hour. Of course we can’t take off or land at that speed. We would need a much longer runway to do that.

Photo credit: Ramon Kok

Flaps

Lift depends on two things—the aircraft’s speed and the curvature of the wing. We adjust the wing’s curvature on takeoff and landing so that the wings provide greater lift. We do that with the help of the flaps. Flaps are long panels on the trailing edge of the wing that we can extend bit-by-bit. Some aircraft also have flaps on the wings’ leading edge—sometimes called slats. After takeoff, as the aircraft increases speed, we retract the flaps.

Ailerons

But you can also see moving parts on the wing’s trailing edge during the flight. These are called ailerons. We use these to make the aircraft turn or to make it bank. By varying the wing’s curvature, we cause one wing to give it more lift than the other. For instance, when we make a left turn, we push the right aileron down which gives it greater curvature and more lift, thereby pushing the left wing down.

Photo credit: Ramon Kok

Speed Brakes

Finally, the wings have long panels along the upper edge. We call these speed brakes. It’s not a true brake. Rather, it “disrupts” the air around the wing. It reduces lift and allows us to descend more quickly, if necessary.

The more I think about it, the more fantastic it is that such an enormous aircraft can fly so easily. It might not be rocket science, but that Bernouilli was certainly a clever guy! Fortunately, steering an aircraft is a lot easier.

Would you like to know more about airplanes? For example, does an airplane have a horn?
